Brača IV is the original world's first 'tear-drop' design and our most widely used paddle. The paddle is designed to facilitate application of power in the beginning (catch) and in the middle of the stroke, enabling capabilities to obtain the “ultimate” forward stroke.
Brača IV 60 is designed for paddlers who prefer a softer blade and shaft.
Brača IV is available in the Extra Light construction for the athletes who prefer light and stiff characteristics. You can also choose the stiffness of the shaft. We recommend a stiffer shaft for bigger blades but any combination is possible. See the shaft stiffness measurement procedure and parameter table below.
Warning: No images in specified directory. Please check the directoy!
Debug: specified directory - https://rowingtest.braca-sport.com/images/paddles
All Brača IV paddles are available with a fixed shaft or a Metal Adjustable Shaft System. This allows elegant adjustment of overall paddle length (within 5cm range) and blade angle from 0° to 80° right or left. The system is also available in the more economical Plastic I. version for the 60% carbon shafts. Both versions allow you to disassemble the paddle into two parts for easy transportation.
Brača IV is also available with Marathon blade construction. This is a result of advanced technology, a proprietary blend of composite materials and was designed with the marathon and adventure paddlers in mind. The edge of the blade is reinforced with a kevlar layer that makes it highly impact resistant in extreme down river conditions.
Always clean your adjustable shaft regularly!
When used in saltwater conditions, clean with freshwater after each use, otherwise disassemble and clean every three days. Store your adjustable paddle disassembled if not used for more than two weeks!
See the maintenance page for details.
Available Options and Technical Parameters:
| NORMAL | Blade | Shaft | Carbon content | Total Weight (g/oz) | |||
|---|---|---|---|---|---|---|---|
 |
Surface area (cm2/in2) | Length (cm) | Width (cm) | Stiffness* (mm) | Blade (%) | Shaft (%) | |
| Brača IV 765 (old size: max) |
765/118.6 | 50.0 | 16.8 | 2.7-2.8 | 100 | 100 | 650/22.9 |
| Brača IV 735 (old size: min) |
735/113.9 | 49.5 | 16.3 | 2.9-3.0 | 100 | 100 | 640/22.6 |
| Brača IV 705 (old size: s-min) |
705/109.2 | 49.0 | 15.8 | 3.1-3.2 | 100 | 100 | 630/22.2 |
| Brača IV 670 | 670/103.9 | 47.5 | 15.2 | 3.3-3.4 | 100 | 100 | 640/22.6 |
| Brača IV 635 (old size: xs-min) |
635/98.4 | 45.3 | 15.1 | 3.3-3.4 | 100 | 100 | 600/21.2 |
| Brača IV 610 | 610/94.5 | 45.0 | 14.4 | 3.3-3.4 | 100 | 100 | 595/21.0 |
* Recommended stiffness. We recommend stiffer shafts for bigger blades but any combination is possible.
| EXTRA LIGHT | Blade | Shaft | Carbon content | Total Weight (g/oz) | |||
|---|---|---|---|---|---|---|---|
|
Surface area (cm2/in2) | Length (cm) | Width (cm) | Stiffness* (mm) | Blade (%) | Shaft (%) | |
| Brača IV 765 Extra Light (old size: max) |
765/118.6 | 50.0 | 16.8 | 2.9-3.0 | 100 | 100 | 600/21.2 |
| Brača IV 735 Extra Light (old size: min) |
735/113.9 | 49.5 | 16.3 | 3.1-3.2 | 100 | 100 | 580/20.5 |
| Brača IV 705 Extra Light (old size: s-min) |
705/109.2 | 49.0 | 15.8 | 3.3-3.4 | 100 | 100 | 560/19.8 |
| Brača IV 670 Extra Light |
670/103.9 | 47.5 | 15.2 | 3.3-3.4 | 100 | 100 | 550/19.6 |
| Brača IV 635 Extra Light (old size: xs-min) |
635/98.4 | 45.3 | 15.1 | 3.3-3.4 | 100 | 100 | 580/20.5 |
* Recommended stiffness. We recommend stiffer shafts for bigger blades but any combination is possible.
| MARATHON | Blade | Shaft | Carbon content | Total Weight (g/oz) | |||
|---|---|---|---|---|---|---|---|
|
Surface area (cm2/in2) | Length (cm) | Width (cm) | Stiffness* (mm) | Blade (%) | Shaft (%) | |
| Brača IV 765 Marathon (old size: max) |
765/118.6 | 50.0 | 16.8 | 2.7-2.8 | 100 | 100 | 650/22.9 |
| Brača IV 735 Marathon (old size: min) |
735/113.9 | 49.5 | 16.3 | 2.9-3.0 | 100 | 100 | 640/22.6 |
| Brača IV 705 Marathon (old size: s-min) |
705/109.2 | 49.0 | 15.8 | 3.1-3.2 | 100 | 100 | 630/22.2 |
| Brača IV 670 Marathon |
670/103.9 | 47.5 | 15.2 | 3.3-3.4 | 100 | 100 | 600/21.2 |
| Brača IV 635 Marathon (old size: xs-min) |
635/98.4 | 45.3 | 15.1 | 3.3-3.4 | 100 | 100 | 600/21.2 |
* Recommended stiffness. We recommend stiffer shafts for bigger blades but any combination is possible.
| SOFT | Blade | Shaft | Carbon content | Total Weight (g/oz) | |||
|---|---|---|---|---|---|---|---|
|
Surface area (cm2/in2) | Length (cm) | Width (cm) | Stiffness* (mm) | Blade (%) | Shaft (%) | |
| Brača IV 765 soft (old size: max) |
765/118.6 | 50.0 | 16.8 | 3.3-3.4 | 100 | 100 | 650/22.9 |
| Brača IV 735 soft (old size: min) |
735/113.9 | 49.5 | 16.3 | 3.3-3.4 | 100 | 100 | 640/22.6 |
| Brača IV 705 soft (old size: s-min) |
705/109.2 | 49.0 | 15.8 | 3.3-3.4 | 100 | 100 | 630/22.2 |
| Brača IV 670 soft |
670/103.9 | 47.5 | 15.2 | 3.3-3.4 | 100 | 100 | 620/21.9 |
* Recommended stiffness. We recommend stiffer shafts for bigger blades but any combination is possible.
| 60% CARBON | Blade | Shaft | Carbon content | Total Weight (g/oz) | |||
|---|---|---|---|---|---|---|---|
|
Surface area (cm2/in2) | Length (cm) | Width (cm) | Stiffness* (mm) | Blade (%) | Shaft (%) | |
| Brača IV 765 60 (old size: max) |
765/118.6 | 50.0 | 16.8 | 3.2-3.4 | 60 | 60 | 780/27.5 |
| Brača IV 735 60 (old size: min) |
735/113.9 | 49.5 | 16.3 | 3.2-3.4 | 60 | 60 | 770/27.2 |
| Brača IV 705 60 (old size: s-min) |
705/109.2 | 49.0 | 15.8 | 3.2-3.4 | 60 | 60 | 760/26.8 |
| Brača IV 670 60 |
670/103.9 | 47.5 | 15.2 | 3.2-3.4 | 60 | 60 | 650/22.9 |
| Brača IV 635 60 (old size: xs-min) |
635/98.4 | 45.3 | 15.1 | 3.3-3.5 | 60 | 60 | 705/24.9 |
| Brača IV 610 60 |
610/94.5 | 45.0 | 14.4 | 3.3-3.5 | 60 | 60 | 690/24.3 |
* Recommended stiffness. We recommend stiffer shafts for bigger blades but any combination is possible.
